Lerobot setup#

SO101 WebSim Follower + DexSuite Teleoperation#

Summary (High-Level)

Repo: EITHER clone the fork OR copy so101_websim_follower into a fresh LeRobot checkout and register it.

Leader Arm: Build SO101 leader arm, install Feetech lib, calibrate and note the teleop.id (e.g. blue).

WebSim Follower: pip install websockets, start WebSocket server (sim), run lerobot-teleoperate with --robot.type=so101_websim_follower.

DexSuite: Kill test server & teleop, run sim_websim_so100.py in DexSuite, run lerobot-teleoperate again pointing to same WS URL.
../_images/droid.png

—

## 0. Prerequisites

  • Working conda environment for LeRobot (and DexSuite if separate).

  • Python version compatible with LeRobot / DexSuite.

  • Access to:

    • SO101 leader arm (hardware).

    • DexSuite repo (for sim_websim_so100.py).

  • Basic Git and terminal usage.

—

## 1. Get the Code

### Option A: Use the fork (quick start)

git clone https://github.com/BMathi9s/lerobot-dexsuite-sim_follower.git
cd lerobot-dexsuite-sim_follower

This repo already contains the so101_websim_follower integration.

### Option B: Integrate into a fresh LeRobot repo

  1. Clone official LeRobot:

    git clone https://github.com/huggingface/lerobot.git
cd lerobot

  2. Copy the follower folder:

    • Source folder (from the fork / backup):

      lerobot/so101_websim_teleoperation/copy of folder and changes made/so101_websim_follower

    • Destination folder (in the fresh repo):

      lerobot/src/lerobot/robots/so101_websim_follower

    After copying, you should have:

    lerobot/
  src/
    lerobot/
      robots/
        ...
        so101_websim_follower/
          __init__.py
          ...

  3. Register the robot in utils.py:

    Open: lerobot/src/lerobot/robots/utils.py

    Inside the if / elif block that chooses robot classes based on config.type, add:

    elif config.type == "so101_websim_follower":
    from .so101_websim_follower import SO101WebSimFollower

    return SO101WebSimFollower(config)

    (There is an example of this in the "copy of folder and changes made" reference.)

  4. Add the import in lerobot_teleoperate.py:

    Open: lerobot/src/lerobot/scripts/lerobot_teleoperate.py

    Ensure the import block includes so101_websim_follower:

    from lerobot.robots import (  # noqa: F401
    Robot,
    RobotConfig,
    bi_so100_follower,
    hope_jr,
    koch_follower,
    make_robot_from_config,
    so100_follower,
    so101_follower,
    so101_websim_follower,
)

—

## 2. Set Up the SO101 Leader Arm

Follow the official SO101 documentation:

  • Docs: https://huggingface.co/docs/lerobot/en/so101

You must:

  1. Build and wire the SO101 leader arm.

  2. Install the Feetech (Feetch) library and any other required packages.

  3. Run the official SO101 calibration script and note the calibration ID, e.g.:

    • blue

    • default

    • etc.

You will use this value later as:

--teleop.id=<your_calibration_id>

—

## 3. Environment & Dependencies

Activate your LeRobot conda environment and install websockets:

conda activate <your_lerobot_env>
pip install websockets

Replace <your_lerobot_env> with your actual environment name.

—

## 4. Start the WebSocket Simulation Server (Test Mode)

Open a new terminal, activate the env, and run one of these:

### Option 1: Server under so101_websim_follower

From the repo root:

conda activate <your_lerobot_env>

python lerobot/src/lerobot/robots/so101_websim_follower/server_test/sim_ws_server.py

### Option 2: Example server script

conda activate <your_lerobot_env>

python lerobot/so101_websim_teleoperation/sim_ws_server_example.py

You should see the server listening on:

ws://127.0.0.1:8765

Keep this terminal running.

—

## 5. Run Teleoperation with SO101 WebSim Follower (Test Mode)

Open another terminal, activate the env, and run:

conda activate <your_lerobot_env>

lerobot-teleoperate \
  --robot.type=so101_websim_follower \
  --robot.ws_url=ws://127.0.0.1:8765 \
  --teleop.type=so101_leader \
  --teleop.port=/dev/ttyACM0 \
  --teleop.id=blue \
  --display_data=false

### Key arguments (must be correct)

  • --robot.type=so101_websim_follower Uses the new virtual follower.

  • --robot.ws_url=ws://127.0.0.1:8765 Must match the server URL.

  • --teleop.type=so101_leader Uses the SO101 leader as teleop device.

  • --teleop.port=/dev/ttyACM0 Replace with the actual serial port of your leader arm.

  • --teleop.id=blue Must match the calibration ID from the SO101 calibration step.

If configuration is correct, you should see:

  • Data printed in the teleop terminal when moving the leader.

  • Messages received in the WebSocket server terminal.

If not, see the Debug section below.

—

## 6. Restart / Check Data if Needed

If no data or errors:

  1. Stop both processes (Ctrl+C in each terminal).

  2. Restart the WebSocket server (step 4).

  3. Restart lerobot-teleoperate (step 5).

  4. Confirm you see messages on the server side when you move the leader.

—

## 7. Connect DexSuite WebSim

Now that the test pipeline works, switch to DexSuite.

  1. Kill the test WS server and teleop process (Ctrl+C in both).

  2. In the DexSuite repo root, run:

    conda activate <your_lerobot_env>  # or DexSuite env if shared

python dexsuite/scripts/teleoperation/lerobot/sim_websim_so100.py

    This script:

    • Starts the WebSim simulation.

    • Provides a WebSocket endpoint (usually also ws://127.0.0.1:8765).

  3. In another terminal, re-run teleop (same as before, adjust env/path as needed):

    conda activate <your_lerobot_env>

lerobot-teleoperate \
  --robot.type=so101_websim_follower \
  --robot.ws_url=ws://127.0.0.1:8765 \
  --teleop.type=so101_leader \
  --teleop.port=/dev/ttyACM0 \
  --teleop.id=blue \
  --display_data=false

  4. Move the SO101 leader arm and confirm the simulated arm in DexSuite moves.

—

## 8. Quick Debug Checklist

Nothing moves in DexSuite:

  • Check DexSuite script (sim_websim_so100.py) and confirm:

    • It listens on ws://127.0.0.1:8765 (or whatever you use).

  • Check that --robot.ws_url in lerobot-teleoperate matches exactly.

No data from leader:

  • Confirm --teleop.port is correct (use ls /dev/tty* on Linux to verify).

  • Confirm Feetech lib is installed and SO101 calibration ran without errors.

  • Confirm --teleop.id = the calibration ID (e.g. blue).

General order that works well:

  1. Start DexSuite script:

    python dexsuite/scripts/teleoperation/lerobot/sim_websim_so100.py

  2. Start teleop:

    lerobot-teleoperate --robot.type=so101_websim_follower ...

—

## 9. Final Pipeline

Once everything is configured and running:

SO101 leader arm (hardware)
   → lerobot-teleoperate (so101_leader)
      → so101_websim_follower (virtual follower)
         → WebSocket (ws://127.0.0.1:8765)
            → DexSuite WebSim (sim_websim_so100.py)

You now have a leader-follower teleoperation setup with a virtual SO101 WebSim follower inside DexSuite.
